ASTM D381 পেট্রোলিয়াম টেস্টিং ইন্সট্রুমেন্টস স্বয়ংচালিত গ্যাসোলিন (এয়ার মেথড) SH8019-এ প্রকৃত গামের সামগ্রী সনাক্তকরণ

উৎপত্তি স্থল চীন
পরিচিতিমুলক নাম Shengtai Instrument
সাক্ষ্যদান ISO9001
মডেল নম্বার SH8019
ন্যূনতম চাহিদার পরিমাণ 1 সেট
প্যাকেজিং বিবরণ কাঠের ক্ষেত্রে
ডেলিভারি সময় 7-15 কর্মদিবস
পরিশোধের শর্ত টি/টি
যোগানের ক্ষমতা 100000সেট/বছর

বিনামূল্যে নমুনা এবং কুপন জন্য আমার সাথে যোগাযোগ করুন.

হোয়াটসঅ্যাপ:0086 18588475571

wechat: 0086 18588475571

স্কাইপ: sales10@aixton.com

আপনার কোন উদ্বেগ থাকলে, আমরা 24-ঘন্টা অনলাইন সহায়তা প্রদান করি।

x
পণ্যের বিবরণ
মডেল SH8019 পাওয়ার সাপ্লাই AC(220±10%)V,50Hz,2500W
বাষ্পীভবন স্নানের মাত্রা Φ260 মিমি * 130 মিমি নমুনা অবস্থান 3টি পদ
নমুনা অবস্থানের মাত্রা Φ51 মিমি * 70 মিমি কাজ তাপমাত্রা (160~165)ºসে
বায়ু হ্রাসকারী ভালভের কাজের চাপ 0.07MPa
লক্ষণীয় করা

পেট্রোলিয়াম টেস্টিং ইন্সট্রুমেন্টস ASTM D381

,

220V পেট্রল আসল গাম টেস্টিং ইন্সট্রুমেন্টস

একটি বার্তা রেখে যান
পণ্যের বর্ণনা

SH8019 Actual colloid tester (air method)

ASTM D381 পেট্রোলিয়াম টেস্টিং ইন্সট্রুমেন্টস স্বয়ংচালিত গ্যাসোলিন (এয়ার মেথড) SH8019-এ প্রকৃত গামের সামগ্রী সনাক্তকরণ 0



SH8019 Existent Gum Tester Jet Evaporation Method Petroleum Tester is specially used for measuring the actual gum content in aviation gasoline and automotive gasoline.

It is suitable for the actual gum test of aviation gasoline and automobile gasoline according to the method specified in ASTM D381 equivalent to GB/T 8019-2008 "Determination of fuel gum content by jet evaporation method". It is equipped with special oil-free silent air compressor.



Product model SH8019
Product Name Air method for actual gum analyzer
Manufacturer Shandong Shengtai Instrument Co., Ltd
Testing items Conduct actual gum test on Avgas and automotive gasoline
Compliant with standards GB/T 8019-2008 "Determination of Gum Content in Fuel - Jet Evaporation Method" equivalent to the method specified in ASTM D381,
Simple technical features Equipped with a dedicated oil-free silent air compressor.



Air Jet Evaporation ASTM D381

ASTM D381 Apparatus for Existent Gum Content of Aviation Fuels, and Motor

ASTM D381 Aviation Fuels and Gasoline Existent Gum Tester

Jet Evaporation Method Petroleum Tester ASTM D381 evaporation



Main technical parameters and performance

Power supply AC(220±10%)V,50Hz,2500W
Dimension of evaporation bath Φ260mm*130mm
Sample positions 3 positions
Dimension of sample positions Φ51mm*70mm
Working temperature (160~165)ºC
Temperature control Automatic temperature control at room temperature of -200 degrees.
Temperature display Digital display
Flow display Displayed by a ball float type flowmeter.
Working pressure of air reducing valve 0.07MPa
Air source External connection, over (1000±150)ml/s
Dimension 590*480*340mm (Thermometer holder is not included)



Packing list

S/N Name Unit Quantity Remarks
1 Host set 1
2 Air compressor set 1
3 Trumpet nozzle piece 3
4 Beaker piece 3
5 purifier set 1
6 Instruction copy 1
7 Packing list copy 1
8 Certificate warranty card copy 1

ASTM D381 পেট্রোলিয়াম টেস্টিং ইন্সট্রুমেন্টস স্বয়ংচালিত গ্যাসোলিন (এয়ার মেথড) SH8019-এ প্রকৃত গামের সামগ্রী সনাক্তকরণ 1

Company Introduction

Shandong Shengtai Instruments Co., Ltd. is specialized in the research and production of experimental testing instruments and industrial testing instruments. It is a professional instrument company integrating instrument research and development, manufacturing, sales and service. Its products are widely used in food, flour, grain and oil, Feed, electricity, petrochemical, industrial oil, aerospace, coal quality and other industries.

For more than 10 years, Shengtai has always been adhering to the "first-class service, customer first" as the purpose, "reasonable price, honesty and trustworthiness" as the business policy. Adhere to technical innovation, with rich knowledge of the technical team and experienced, thoughtful after-sales service team.

Shengtai instrument as one of the most large-scale and competitive enterprises in the industry, with the strength of technology research and development, professional technical knowledge and innovative design concept, in the model improvement, Significant technical breakthrough has been achieved in the development of function expansion and intelligent control system.

OUR service

After-sales service commitment, our company to sell the product after-sales service commitment: warranty period of one year, long-term technical support outside the warranty period. During the warranty period, the seller shall bear the cost of the replacement of the equipment, the freight and maintenance of the instrument; outside the warranty period, the seller shall waive the maintenance fee and charge only the cost of the basic materials and freight charges when the instrument is malfunctioning and the seller shall not charge the maintenance fee during the warranty period.

Packaging & Delivery

1. Out packing: Standard export wooden case.
2. Inner packing: With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.

4.Port Any port of China

Lead Time :

Quantity(Sets) 1 - 1 2 - 5 6 - 10 >10
Est. Time(days) 6 20 30 To be negotiated

Contact us

Shandong Shengtai Instrument Co.,ltd

ADD:6-8 time base NO.15 lanxiang road tianqiao Area Jinan city

TEL:+86 0531-85919987 85929987

FAX:+86 0531-85957987

Whatsapp/facebook:+86 13370527859

QQ:3206156217

Email:3206156217@qq.com

Web:www.labtool.net/en
